  • ASRock Super Alloy
    - Premium Alloy Choke (Reduces 70% core loss compared to iron powder choke)
    - NexFET™ MOSFET
    - Sapphire Black PCB
    ASRock Full Spike Protection
    ASRock Cloud
    ASRock APP Shop
  • - Supports 5th Generation Intel® Core™ i7 / i5 / i3 / Pentium® / Celeron® Processors (Socket 1150)
    - Supports New 4th and 4th Generation Intel® Xeon® / Core™ i7 / i5 / i3 / Pentium® / Celeron® Processors (Socket 1150)
    - Digi Power design
    - 4 Power Phase design
    - Supports Intel® Turbo Boost 2.0 Technology
  • - Intel® H97
    - Supports Intel® Small Business Advantage 2.0
  • - Dual Channel DDR3/DDR3L Memory Technology
    - 4 x DDR3/DDR3L DIMM Slots
    - Supports DDR3/DDR3L 1600/1333/1066 non-ECC, un-buffered memory
    - Max. capacity of system memory: 32GB*
    - Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2
    *Az operációs rendszer korlátai miatt a tényleges memóriaméret kevesebb lehet 4 GB-nál, mert a rendszer 32 bites Windows® operációs rendszer alatt saját használatra fenntartja egy részét.. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation.
  • - 128Mb AMI UEFI Legal BIOS with multilingual GUI support
    - ACPI 1.1 Compliant wake up events
    - SMBIOS 2.3.1 support
    - CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage multi-adjustment
  • - Supports Intel® HD Graphics Built-in Visuals : Intel® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel® InTru™ 3D, Intel® Clear Video HD Technology, Intel® Insider™, Intel® HD Graphics 4400/4600
    - Pixel Shader 5.0, DirectX 11.1
    - Max. shared memory 512MB*
    - Three graphics output options: D-Sub, DVI-D and HDMI
    - Supports Triple Monitor
    - Supports HDMI with max. resolution up to 1920x1200 @ 60Hz
    - Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
    - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
    - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
    - Supports HDCP with DVI-D and HDMI Ports
    - Supports Full HD 1080p Blu-ray (BD) playback with DVI-D and HDMI Ports
    *A megosztott memória maximális mérete operációs rendszerenként eltérő.
    **Az Intel® HD Graphics Built-in Visuals és VGA támogatása csak beépített GPU-val rendelkező processzorok esetében lehetséges.
    ***Due to chipset limitation, the Blu-ray playback of Intel® HD Graphics is only supported under Windows® 8 / 8 64-bit / 7 / 7 64-bit.
    ****Intel® InTru™ 3D is only supported under Windows® 8 / 8 64-bit / 7 / 7 64-bit.
  • - 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)
    - Premium Blu-ray Audio support
    - Supports Surge Protection (ASRock Full Spike Protection)
    - ELNA Audio Caps
  • - Gigabit LAN 10/100/1000 Mb/s
    - Giga PHY Intel® I218V
    - Supports Intel® Remote Wake Technology
    - Supports Wake-On-LAN
    - Supports Lightning/ESD Protection (ASRock Full Spike Protection)
    - Supports Energy Efficient Ethernet 802.3az
    - Supports PXE
  • - 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
    - 1 x PCI Express 2.0 x16 Slot (PCIE2: x4 mode)
    - 2 x PCI Slots
    - Supports AMD Quad CrossFireX™ and CrossFireX™
  • - 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel® Rapid Storage Technology 13 and Intel® Smart Response Technology), NCQ, AHCI and Hot Plug
  • - 1 x Print Port Header
    - 1 x COM Port Header
    - 1 x Chassis Intrusion Header
    - 1 x TPM Header
    - 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
    - 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin)
    - 1 x Power Fan Connector (3-pin)
    - 1 x 24 pin ATX Power Connector
    - 1 x 8 pin 12V Power Connector
    - 1 x Front Panel Audio Connector
    - 1 x Thunderbolt™ AIC Connector*
    - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
    - 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection (ASRock Full Spike Protection))
    *Frissítsen e legújabb BIOS-ra a Thunderbolt™ technológia támogatásához.
  • - 1 x PS/2 Mouse/Keyboard Port
    - 1 x D-Sub Port
    - 1 x DVI-D Port
    - 1 x HDMI Port
    - 1 x Optical SPDIF Out Port
    - 2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))
    - 4 x USB 3.1 Gen1 Ports (Supports ESD Protection (ASRock Full Spike Protection))
    - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
    - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
  • Software
    - ASRock A-Tuning
    - ASRock Disk Health Report
    - ASRock USB Key
    - ASRock System Browser
    - ASRock APP Charger
    - ASRock XFast LAN
    - ASRock XFast RAM
    - ASRock Restart to UEFI
    UEFI
    - ASRock Full HD UEFI
    - ASRock My Favorites in UEFI
    - ASRock UEFI Guide
    - ASRock Instant Flash
    - ASRock Internet Flash
    - ASRock Crashless BIOS
    - ASRock OMG (Online Management Guard)
    - ASRock UEFI Tech Service
    - ASRock Dehumidifier
    - ASRock Easy RAID Installer
    - ASRock Easy Driver Installer
  • - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar, Start8 (30 days trial), Orbweb.ME Professional (Win 8.1)
  • - Quick Installation Guide, Support CD, I/O Shield
    - 2 x SATA Data Cables
  • - CPU, Chassis temperature sensing
    - CPU, Chassis, Power Fan Tachometer
    - CPU, Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature)
    - CPU, Chassis Fan multi-speed control
    - CASE OPEN detection
    - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
  • - Micro ATX Form Factor
    - Solid Capacitor design
    - High Density Glass Fabric PCB
  • - Microsoft® Windows® 10 64-bit / 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit
  • - FCC, CE
    - ErP/EuP ready (ErP/EuP ready power supply is required)
Ram

Asrock H97m Pro4 Ram Slots Free

  • ASRock Super Alloy
    - Premium Alloy Choke (Reduces 70% core loss compared to iron powder choke)
    - NexFET™ MOSFET
    - Sapphire Black PCB
    ASRock Full Spike Protection
    ASRock Cloud
    ASRock APP Shop
  • - Supports 5th Generation Intel® Core™ i7 / i5 / i3 / Pentium® / Celeron® Processors (Socket 1150)
    - Supports New 4th and 4th Generation Intel® Xeon® / Core™ i7 / i5 / i3 / Pentium® / Celeron® Processors (Socket 1150)
    - Digi Power design
    - 4 Power Phase design
    - Supports Intel® Turbo Boost 2.0 Technology
  • - Intel® H97
    - Supports Intel® Small Business Advantage 2.0
  • - Dual Channel DDR3/DDR3L Memory Technology
    - 4 x DDR3/DDR3L DIMM Slots
    - Supports DDR3/DDR3L 1600/1333/1066 non-ECC, un-buffered memory
    - Max. capacity of system memory: 32GB*
    - Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2
    *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation.
  • - 128Mb AMI UEFI Legal BIOS with multilingual GUI support
    - ACPI 1.1 Compliant wake up events
    - SMBIOS 2.3.1 support
    - CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage multi-adjustment
  • - Supports Intel® HD Graphics Built-in Visuals : Intel® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel® InTru™ 3D, Intel® Clear Video HD Technology, Intel® Insider™, Intel® HD Graphics 4400/4600
    - Pixel Shader 5.0, DirectX 11.1
    - Max. shared memory 512MB*
    - Three graphics output options: D-Sub, DVI-D and HDMI
    - Supports Triple Monitor
    - Supports HDMI with max. resolution up to 1920x1200 @ 60Hz
    - Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
    - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
    - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
    - Supports HDCP with DVI-D and HDMI Ports
    - Supports Full HD 1080p Blu-ray (BD) playback with DVI-D and HDMI Ports
    *The size of maximum shared memory may vary from different operating systems.
    **Intel® HD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.
    ***Due to chipset limitation, the Blu-ray playback of Intel® HD Graphics is only supported under Windows® 8 / 8 64-bit / 7 / 7 64-bit.
    ****Intel® InTru™ 3D is only supported under Windows® 8 / 8 64-bit / 7 / 7 64-bit.
  • - 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)
    - Premium Blu-ray Audio support
    - Supports Surge Protection (ASRock Full Spike Protection)
    - ELNA Audio Caps
  • - Gigabit LAN 10/100/1000 Mb/s
    - Giga PHY Intel® I218V
    - Supports Intel® Remote Wake Technology
    - Supports Wake-On-LAN
    - Supports Lightning/ESD Protection (ASRock Full Spike Protection)
    - Supports Energy Efficient Ethernet 802.3az
    - Supports PXE
  • - 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
    - 1 x PCI Express 2.0 x16 Slot (PCIE2: x4 mode)
    - 2 x PCI Slots
    - Supports AMD Quad CrossFireX™ and CrossFireX™
  • - 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel® Rapid Storage Technology 13 and Intel® Smart Response Technology), NCQ, AHCI and Hot Plug
  • - 1 x Print Port Header
    - 1 x COM Port Header
    - 1 x Chassis Intrusion Header
    - 1 x TPM Header
    - 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
    - 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin)
    - 1 x Power Fan Connector (3-pin)
    - 1 x 24 pin ATX Power Connector
    - 1 x 8 pin 12V Power Connector
    - 1 x Front Panel Audio Connector
    - 1 x Thunderbolt™ AIC Connector*
    - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
    - 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection (ASRock Full Spike Protection))
    *Please update to the latest BIOS to support Thunderbolt™ technology.
  • - 1 x PS/2 Mouse/Keyboard Port
    - 1 x D-Sub Port
    - 1 x DVI-D Port
    - 1 x HDMI Port
    - 1 x Optical SPDIF Out Port
    - 2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))
    - 4 x USB 3.1 Gen1 Ports (Supports ESD Protection (ASRock Full Spike Protection))
    - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
    - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
  • Software
    - ASRock A-Tuning
    - ASRock Disk Health Report
    - ASRock USB Key
    - ASRock System Browser
    - ASRock APP Charger
    - ASRock XFast LAN
    - ASRock XFast RAM
    - ASRock Restart to UEFI
    UEFI
    - ASRock Full HD UEFI
    - ASRock My Favorites in UEFI
    - ASRock UEFI Guide
    - ASRock Instant Flash
    - ASRock Internet Flash
    - ASRock Crashless BIOS
    - ASRock OMG (Online Management Guard)
    - ASRock UEFI Tech Service
    - ASRock Dehumidifier
    - ASRock Easy RAID Installer
    - ASRock Easy Driver Installer
  • - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar, Start8 (30 days trial), Orbweb.ME Professional (Win 8.1)
  • - Quick Installation Guide, Support CD, I/O Shield
    - 2 x SATA Data Cables
  • - CPU, Chassis temperature sensing
    - CPU, Chassis, Power Fan Tachometer
    - CPU, Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature)
    - CPU, Chassis Fan multi-speed control
    - CASE OPEN detection
    - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
  • - Micro ATX Form Factor
    - Solid Capacitor design
    - High Density Glass Fabric PCB
  • - Microsoft® Windows® 10 64-bit / 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit
  • - FCC, CE
    - ErP/EuP ready (ErP/EuP ready power supply is required)
